铝型材挤压机主要参数 |
|
使用压力
(MPa) |
柱塞直径
(MM) |
主辅助油缸规格
(MM) |
使用棒料规格
(MM) |
主机中心高
(MM) |
出料口尺寸
(MM) |
总功率
(KW) |
外形尺寸
(MM) |
总重量
(吨) |
500T
(550UST) |
21 |
520 |
 125X 70
|
 80X380
|
880 |
 120
|
84.5 |
5750X3200X2600 |
20 |
600T
(660UST) |
21 |
580 |
 160X 120
|
 90X470
|
870 |
 120
|
90.5 |
6500X3230X2950 |
22 |
800T
(880UST) |
21 |
650 |
 180X 140
|
 110X520
|
1010 |
 160
|
155.5 |
7140X3700X3500 |
38 |
1000T
(110UST) |
21 |
730 |
 200X 150
|
 120X580
|
1080 |
 160
|
160 |
7410X3700X3750 |
44 |
1250T
(1400UST) |
21 |
840 |
 200X 150
|
 140X650
|
1210 |
 180
|
208.6 |
8750X4300X4050 |
62 |
1650T
(1800UST) |
21 |
950 |
 220X 160
|
 178X700
|
1320 |
 210X250
|
300 |
9200X4670X4680 |
80 |
2000T
(2200UST) |
21 |
1050 |
 250X 180
|
 200X800
|
1630 |
 280X320
|
340 |
15830X5020X5510 |
130 |
2500T
(2750UST) |
21 |
1180 |
 250X 180
|
 240X900
|
1865 |
 310X380
|
540 |
16550X6100X6350 |
203 |
3300T
(3600UST) |
21 |
1350 |
 300X 220
|
 280X1000
|
2310 |
 380X450
|
896 |
18500X6530X8040 |
300 |
|
|
 |
